Inside Diameter: | 76-152mm |
Polish Group: | 8 groups |
Parent Length: | 1500~3000mm(standard) |
Coating: | spray or shower coating |
Total Power: | About 50Kw |
Speed: | 3-5m/min |
Feeding and Outing Mode: | Auto |
Polishing Mode: | sand belt polish |
Dust Cleaning Packed Group: | 1 set |
Operator: | 1 person |
Size Adjustment (ID): | Motor-driven |
Overall Size: | 16500 x 5600 x 3250mm |
Machine Main functions:
l Adopt human-machine interface and specialized operation system, easier to operate;
l Automatic tube loading, feeding and unloading, improving production efficiency and reducing cost;
l Whole-closed mechanism, avoiding dust pollution;
l Equipped with 8 abrasive bands from rough polish to fine polish, finishing polish work one-time;
l Another 6 pcs belts adopting sanding belts or grinding belts after waxing, ensure better polishing.
l Each polishing process is equipped with a dust collector, more cleaner;
l Wax coating case in waxing device, waxing tube automatically;
l Main bearing adopts NSK or SKF brands, for long-time using;
